Can Metal Be Used for Injection Molding?
I know plastic is used in injection molding, but is it possible to use metal?
The answer is yes and no. Yes, metal can be used in injection molding, but not by itself. In order to get the powdered metal to take the shape of the mold and hold the shape, about 20% of plastic is added to approximately 80% powdered metal. These pellets are called feedstock and they are melted and pushed into the mold.
After this point, the part is not complete like it may be with plastic injection molding. The metal part needs to go through the debinding process in order to remove all of the plastic. You cannot leave the part alone after debinding, because it is very fragile and you can think of it like a sandcastle like structure. Then the metal parts go through the sintering process to strengthen the part and remove the holes that were left behind by the plastic.
We most commonly use stainless steel powder. Titanium is another metal that we commonly work with. There are some metals that are not compatible with our process. We do not use aluminum, zinc, brass, magnesium or copper in the metal injection molding process.
If you want to learn more about the whole process, see the "What is MIM?" section of our website.
